Combined Island Freezer
Combined island freezer for supermarkets, convenience stores, fresh food stores, frozen food areas and commercial retail projects. Designed with end cabinet, middle cabinet and covered cabinet options for flexible frozen food display layouts.
MODULAR FROZEN FOOD DISPLAY

Commercial Combined Island Freezers

Guangjie combined island freezers are designed for supermarket frozen-food aisles, convenience stores and fresh-food retail areas. End cabinets and straight cabinets can be combined into flexible island layouts for frozen meat, seafood, ice cream, dumplings, hot-pot ingredients and packaged frozen food.

SERIES OVERVIEW
Cabinet types: End and straight cabinets
       Capacity range: 660L to 820L
       Cabinet length: 1.8m and 2.1m options
       Layout: Modular island combinations
       Application: Commercial frozen display
MODEL REFERENCE

Choose the Cabinet by Layout and Display Capacity

The following specifications are reference values from the current product catalogue. Final electrical, temperature and refrigeration configurations should be confirmed before ordering.

ISLAND END CABINET
1.8m End Cabinet
Overall size: 1860 × 810 × 840mm
           Internal size: 1700 × 650 × 600mm
           Capacity: 660L
           Cooling capacity: 600W
STANDARD STRAIGHT CABINET
1.8m Straight Cabinet
Overall size: 1860 × 810 × 900mm
           Internal size: 1700 × 650 × 650mm
           Capacity: 720L
           Cooling capacity: 600W
LARGE STRAIGHT CABINET
2.1m Straight Cabinet
Overall size: 2100 × 810 × 900mm
           Internal size: 1940 × 650 × 650mm
           Capacity: 820L
           Cooling capacity: 700W

Plan the Island Freezer Around the Retail Layout

Confirm the aisle width, available floor area, display capacity and planned island shape before selecting the cabinet combination.

End Cabinet Position
End cabinets complete the head of an island row and help create a continuous frozen-food display layout.
Straight Cabinet Quantity
Straight cabinets can be repeated according to the required island length and frozen-food display volume.
Aisle Clearance
Leave sufficient customer access, product-loading space and service clearance around the freezer island.
Electrical Planning
Confirm voltage, frequency, plug type, power supply position and destination-market requirements before production.
CATALOGUE CONFIGURATION
Commercial Refrigeration Features
Precise temperature control
         Branded compressor configuration
         3D circulating refrigeration
         Integral cabinet foaming
         Sliding glass display lids
         Low-energy and low-noise operation
QUOTATION CHECKLIST
Information Required Before Ordering
1. Available floor area and aisle width
         2. Required end and straight cabinet quantity
         3. Expected frozen-food display volume
         4. Required operating temperature
         5. Voltage, frequency and plug type
         6. Refrigerant and branding requirements
         7. Destination country or delivery port
Compare Other Island Freezer Structures
Flat-glass island freezers are suitable when buyers need an independent horizontal cabinet rather than a modular end-and-straight cabinet combination.
Need a Combined Island Layout for Your Store?
Send the floor plan, aisle width, cabinet quantity, electrical requirements and destination for model and layout confirmation.
